Construction Mesh 2x2 Electro Galvanized Welded Wire Mesh Sheet
Product Description
PVC coated Welded Mesh Fence panel
Galvanized welded wire mesh sheet is welded by high quality low-carbon steel wire or galvanized steel wire, then PVC coating.
Compared with general iron welded wire mesh panel, the PVC coated welded wire mesh panel is better in respects of anti-corrosive, anti-rust, non-fading, anti-ultraviolet radiation, and have bright color.
Weaving And Characteristics:
Galvanizing after welding,galvanizing before welding;surface treatment types include hot dip galvanized,eletro galvanizing,PVC sprayed coating,PVC dipped coating,specifical-type welded wire mesh;has the characteristics as anti-corrosion,anti-oxidation and so on.
Specification
Material : Low carbon steel wire
Color : yellow, dark green orange, red, green, blue white, black, etc
Finishing: Galvanized / powder coated
Type: panel
| Specification of PVC coated welded wire mesh panel |
| Mesh in mm | Mesh in inch | Wire Gauge | Wire dia before coat | Wire dia after coat |
| 6.4mm | 1/4 Inch | 22,23,24 | 0.56mm-0.71mm | 0.90mm-1.05mm |
| 9.5mm | 3/8 Inch | 19,20,21,22 | 0.64mm-1.07mm | 1.00mm-1.52mm |
| 12.7mm | 1/2 Inch | 16,17,18,19,20,21,22,23 | 0.71mm-1.65mm | 1.10mm-2.20mm |
| 15.9mm | 5/8 Inch | 18,19,20,21 | 0.81mm-1.65mm | 1.22mm-2.30mm |
| 19.1mm | 3/4 Inch | 16,17,18,19,20,21 | 0.81mm-1.65mm | 1.24mm-2.40mm |
| 25.4mmx12.7mm | 1x1/2 Inch | 16,17,18,19,20,21 | 0.81mm-1.65mm | 1.24mm-2.42mm |
| 25.4mm | 1 Inch | 14,15,16,17,18,19,20 | 0.81mm-2.11mm | 1.28mm-2.90mm |
| 38.1mm | 1 1/2 Inch | 14,15,16,17,18,19 | 1.07mm-2.11mm | 1.57mm-2.92mm |
| 25.4mmx50.8mm | 1x2 Inch | 14,15,16 | 1.47mm-2.11mm | 2.00mm-2.95mm |
| 50.8mm | 2Inch | 12,13,14,15,16 | 1.65mm-2.77mm | 2.20-mm3.61mm |
| 76.2mm | 3Inch | 16,17,18 | 1.90mm-3.50mm | 2.50mm-4.36mm |
| 101.6mm | 4Inch | 12,13,14,15,16 | 2.20mm-4.00mm | 2.85mm-4.88mm |
| Note: 1. Width 0.5m-1.8m, length 1m-8m. 2. Special sizes available at request. 3. Packing: packed on pallet or as your requirement. 4. Sample is free within 1 or 2, express cost need pay before shipping. |
| Galvanized Fence Mesh |
| Opening | Wire Diameter |
| In "inch" | In Metric Unit (mm) |
| 2'' X 3'' | 50mm X 70mm | 2.0mm, 2.5mm, 1.65mm |
| 3'' X 3'' | 75mm X 75mm | 2.67mm, 2.41mm, 2.11mm, 1.83mm, 1.65mm |
| 2'' X 4'' | 50mm X 100mm | 2.11mm, 2.5mm |
| 4'' X 4'' | 100mm X 100mm | 2.0mm, 2.5mm |
Application:
Widely used in dustry, agriculture, construction, transportation, mining and other industries. Mainly used in general building external wall, concrete, highirise residential and so on, in the structure of heat preservation system plays an important role.
