Weave Diamond Steel Wire Fencing , Roll Strong Wire Fencing For Garden
Product Description
Chain link mesh netting is made of woven steel wire, which is one of the most commonly used and versatile of all the fencing fabrics. It is normally available in a variety of wire gauges and mesh sizes to suit individual applications. All chain link rolls come complete with line wires and with knuckled edges. Barbed (protruding) edges increase the security of the fencing and are available to order.
Material:Low Carbon Steel wire
Mesh:1"-4" (1, 1.5, 2, 2.25, 2.4,2.5, 3, 4 inch)
Diameter: 1-4.5mm
Width: 0.5-5m and as you need
Technique: Twist or Knuckle
Colour: Green, Yellow, Blue, Red, Silver and White, etc
Type: Panel with Post or Roll
Finish:Hot dipped galvanized ,Electro galvanized,PVC coated
Specification:
-- Details of Galvanized Chain Link Fence
| mesh (mm) | wire guage (SWG) | Wire Diameter (mm) | Weight Kg/m2 | Coil Diameter |
| (cm) |
| Natural volume | Fold volume |
| 200*200 | 8 | 4.06 | 1 | 60 | 35 |
| 150*150 | 10 | 3.25 | 0.9 | 55 | 32 |
| 100*100 | 9 | 3.66 | 1.7 | 55 | 35 |
| 80*80 | 10 | 3.25 | 1.68 | 57 | 38 |
| 60*60 | 12 | 2.64 | 1.5 | 52 | 34 |
| 50*50 | 12 | 2.64 | 1.83 | 49 | 33 |
| 40*40 | 10 | 3.25 | 3.56 | 46 | 32 |
| 30*30 | 12 | 2.64 | 3.25 | 42 | 34 |
| 20*20 | 19 | 1.02 | 0.7 | 25 | 34 |
-- .Details of PVC Coated Chain Link Fence
| mesh (mm) | wire guage (SWG) | Wire Diameter (mm) | Weight Kg/m2 | Coil Diameter |
| (cm) |
| Natural volume | Fold volume |
| 80×80 | 8 | 3.0/4.06 | 1.72 | 65 | 40 |
| 60×60 | 9 | 2.6/3.66 | 1.75 | 59 | 38 |
| 55×55 | 10 | 2.2/3.25 | 1.38 | 54 | 35 |
| 50×50 | 10 | 2.2/3.25 | 1.67 | 49 | 35 |
| 45×45 | 8 | 3.0/4.0 | 3.2 | 50 | 35 |
| 40×40 | 10 | 2.2/3.25 | 2 | 45 | 34 |
| 35×35 | 12 | 2.0/2.64 | 1.9 | 40 | 30 |
Main Features &Characteristic:
Chain link fencings are one of the most well known perimeter fencings since they are easy to build,cost effective and long lasting,fulfilling the motive of keeping people in/out of a particular region.
1) Simple structure in linear type ,convenient instation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,with wide application, electric parts and operation parts.
3) High pressure double crank to control the die opening and closing. safe and flexible;
4) Spiked top and bottom for additional security.
Does not sag or roll up at the bottom
Packing:
1) There are some different packagings of chain link fence for you. Please choose according to your needs.
2) woven bags of the above and bottom,high quality package or as customes requested
3) In roll ,water proof paper in side and our side with weave bag;carton;wooden case; or pallet.
Diamond Chain Link Fence Application
Diamond mesh is used as fencing for sports field, river banks, construction and residence, also animal fencing. Especially, well suitable for a wide range of application, for example for enclosing Lawn, Road. Steel diamond mesh has a heavy galvanized coating to ensure a long life.
